Professional-grade energy storage solutions—HS-YD15KW driving the energy transformation of industrial and commercial sectors
The HS-YD15KW is a high-performance 15 kWh intelligent energy storage system specifically designed for industrial and commercial applications. It integrates efficient energy storage, intelligent management, and multi-layered safety protection to provide businesses with stable and reliable power supply and energy optimization solutions.
Core Advantages
Large-capacity flexible expansion: 15 kWh standard capacity to meet the power needs of different-scale applications
Intelligent Energy Management: AI algorithms automatically optimize charging and discharging strategies, enabling peak-valley arbitrage, with the potential to reduce electricity costs by up to 50%
Military-Grade Safety Assurance: Utilizes automotive-grade lithium iron phosphate battery cells, certified to UL1973 standards, and equipped with a three-level BMS protection system
High-Efficiency and Stable Operation: 98% system conversion efficiency, supports multi-source input from solar power, grid power, and generators, with seamless switching time <10ms
Technical Specifications
▸ Rated Capacity: 15kWh
▸ Battery Type: LiFePO₄ Lithium Iron Phosphate
▸ Cycle Life: ≥6000 cycles (80% DoD)
▸ Continuous Power: 15kW
▸ Operating Temperature: -30°C to 60°C
Application Scenarios
✓ Power optimization for factory workshops
✓ Energy storage for commercial complexes
✓ Integrated photovoltaic-storage-charging power plants
✓ Backup power for communication base stations
✓ Energy storage for agricultural photovoltaic systems
Quality Commitment: Certified by TÜV, CE, IEC 62619, and other international standards, with an 8-year or 8,000-cycle warranty
The HS-YD15KW energy storage system provides businesses with more economical, intelligent, and reliable energy solutions, supporting the transition to a green and low-carbon future!
|
Model
|
HS-YD15KW
|
|
Rated Voltage（V）
|
51.2
|
|
Rated Capacity（Ah）
|
280
|
|
Rated Energy（Wh）
|
14336
|
|
Voltage Range（V）
|
44.8-56
|
|
Charge Voltage Range（V）
|
56-57.6
|
|
Cut-off Voltage（V）
|
44.8
|
|
Recommend Charge Current（A）
|
50
|
|
Max Charge Current（A）
|
100
|
|
Max Discharge Current（A）
|
100
|
|
Ouput Peak power
|
Max 6000W peak
|
|
Battery Type
|
LiFePO4 280Ah*16PCS 16S1P
|
|
AC Input
|
2500W(Parameters can be set)
|
|
MPPT PV Input
|
120-500V 5500W Max
|
|
AC output
|
AC 230V 1500W*3 Pure sine wave
|
|
Indicator
|
LCD screen to show AC volt, power percentage,Frenquency Hz.
|
|
Shell material
|
Metal
|
|
Product weight
|
≈120.2kg
|
|
Dimension
|
L695*W330*H940mm(Height including base)
|
|
Color
|
Dark gray
|
